SUN-QSFP-LR4 40G Optical Transceiver

Model: SUN-QSFP-LR4

40G QSFP Optical Transceiver,suitable for single mode, max transmitter distance:10km

    Key Features

  • Transmission data rate up to 11.2Gbps per channel
  • QSFP+ MSA compliant
  • Compliant to IEEE 802.3ba specification for 40GBASE-LR4 links
  • 4 CWDM un-cooled DFB lasers, using ITU G.694.2 wavelength grid at 1271, 1291, 1311, and 1331nm
  • High Sensitivity PIN-TIA with optical DEMUX
  • Up to 10km reach over standard single mode fiber
  • Compliant with QDR/DDR Infiniband data rates
  • Hot pluggable electrical interface
  • Lower power consumption
  • Operating case temperature：Standard: 0~+70°C
  • Operating case temperature：Industrial: -40~+85°C
  • Description
  • Specifications
  • Ordering Information
  • Applications
  • FAQ
  • Product Video
  • Sun Telecom’s SUN-QSFP-LR4 Series Product is a 4x10G hot pluggable optical transceiver. The technology enables the integration of 4 transmitters, 4 receivers and an optical MUX/DeMUX into a small form factor package that delivers a 40 Gbps data link in a compact QSFP footprint. The optical connectivity is based on two SMF LC connectors, one for Tx and one for Rx. The Tx and Rx each consist of 4 10GB/s CWDM channels, whose wavelengths are in the 1300nm range. The QSFP-LR transceiver is designed for applications based on the IEEE 802.3ba 40BASE-LR4 standard of up to 10km reach.
  • Absolute Maximum Ratings
    Parameter Symbol Min Max Units
    Supply Voltage Vcc-Tx
    Vcc-Rx
    Vcc1    		 0 3.6 V
    Storage Temperature Tstg -40 85 ºC
    Maximum Average Input Optical Power per lane (Damage Threshold) PIN 3.3   dBm
    Relative Humidity (Non-condensation) RH 10 90 %

    Operating Conditions
    Parameter Symbol Min Max Units
    Supply Voltage Vcc-Tx
    Vcc-Rx
    Vcc1    		 3.1 3.5 V
    Operating Case Temperature Tcase 0 70 ºC
    Power Consumption PDISS   3.5 W
    SMF Link Length LKM   10 KM

    High Speed Electrical Specifications
    Parameter Min Typical Max Units
    General
    Supply Voltage 3.1 3.3 3.5 V
    Supply Current     1 A
    Maximum Power Consumption     3.5 W
    Maximum Power Consumption-LP Mode     1.5 W
    Signaling Speed Per Channel   10.3125   Gb/s
    Signaling Speed Operating Range   ±100   ppm
    Transmitter
    Transmitter Differential Input Impedance   100   Ω
    Transmitter Differential Input Voltage 0.2   1.6 V
    Receiver
    Differential Output Impedance   100   Ω
    Differential Output Voltage   300 850 mV
    Rise Time     60 Ps
    Fall Time     60 ps

    Optical Characteristics
    Parameter Min Typical Max Units
    Transmitter
    Lane Wavelength Range 1264.5
    1284.5
    1304.5
    1324.5    		 1271
    1291
    1311
    1331    		 1277.5
    1297.5
    1317.5
    1337.5    		 nm
    Data Rate Per Lane   10.3125   Gb/s
    Average Optical Power Per Lane -7.6   2.4 dBm
    Total Average Launch Power     8.3 dBm
    Optical Modulation Amplitude (OMA), Each Lane -4   3.5 dBm
    Extinction Ratio 3.5     dB
    Difference in Launch Power between any Two Lanes     6.5 dB
    Relative Intensity Noise (RIN)     -128 dB/Hz
    Launch Power in OMA Minus TDP, Each Lane -4.8     dBm
    Transmitter and Dispersion Penalty (TDP), Each Lane     2.6 dB
    Side-Mode Suppression Ratio (SMSR) 30     dB
    Average Launch Power Per Lane @ TX Off Stat     -30 dB
    Transmitter Reflectance     -12 dB
    Optical Return Loss Tolerance     20 dB
    Transmitter Eye Mask Definition: X1, X2, X3, Y1, Y2, Y3 Compliant with 802.3ba standard {0.25, 0.4, 0.45, 0.25, 0.28, 0.4}
    Eye Mask Criteria 5% mask margin over specified ranges of temperature, voltage and power supply noise at end of life
    Receiver
    Lane Wavelength Range 1264.5
    1284.5
    1304.5
    1324.5    		 1271
    1291
    1311
    1331    		 1277.5
    1297.5
    1317.5
    1337.5    		 nm
    Damage Threshold 3.3     dBm
    Average Receive Power, Each Lane -13.7   2.3 dBm
    Receive Power, Each Lane (OMA)     3.5 dBm
    Difference in Receive Power between any Two Lanes (OMA)     7.5 dB
    Receiver Reflectance     -26 dB
    Receiver Sensitivity (OMA) Per Lane (10.3125Gb/s @ PRBS 231-1 and BER=10-12)     -11.5 dBm
    Receiver 3 dB Electrical Upper Cutoff Frequency, Each Lane     12.3 GHz
    Stressed Receiver Sensitivity OMA), Each Lane     -9.6 dBm
    Vertical Eye Closure Penalty, Each Lane 1.9     dB
    Stressed Eye Jitter Per Lane 0.3     UI

  • Model Name Description
    SUN-QSFP-40G-LR4 SFP Module 40Gb/s QSFP+ LR4,Pull-Tab,10 km on a standard single mode fiber,0 to +70°C
    SUN-QSFP-40G-LR4-I SFP Module 40Gb/s QSFP+ LR4,Pull-Tab,10 km on a standard single mode fiber,-40 to +85°C

  • ● 40G Ethernet and OTU3
    ● Infiniband QDR and DDR interconnects
    ● Client-side 40G Telecom connections
