> Fiber Optic Distribution Frame
Max cores: 504/576/720, HD series can be used with ODF units
| Parameters | Specification | |
|
Model
|
SUN-ODF-HA
|
SUN-ODF-HD
|
|
Maximum Number of Cores
|
504/576/720
|
504/576
|
|
Cabinet Material
|
Cold-rolled steel (1.2mm thick)
|
|
|
Adapter Type
|
FC square, SC, DLC (SC type) (ST,FC small D can be customized)
|
|
|
Insulation Resistance (MΩ)
|
1000 @500V (DC)
|
|
|
Withstanding Voltage (V(D.C)/1min)
|
≥3000, no breakdown, no flashover
|
|
|
Dimensions (mm)
|
600(W) x 2000(H) x 300(D)
600(W) x 2200(H) x 300(D) 600(W) x 2600(H) x 300(D) |
840(W) x 2000(H) x 300(D)
840(W) x 2200(H) x 300(D) |
|
Weight (kg)
|
68/72/90
|
98.5/105
|
| Model | SUN-ODF-HA504 | SUN-ODF-HA576 | SUN-ODF-HA720 | SUN-ODF-HD504 | SUN-ODF-HD576 | ||
|
No.
|
Product
|
Unit
|
Quantity
|
||||
|
1
|
Frame
|
set
|
1
|
1
|
1
|
1
|
1
|
|
2
|
Protective Tube
|
piece
|
1
|
1
|
1
|
1
|
1
|
|
3
|
Protective Sleeves
|
pieces
|
504
|
576
|
720
|
504
|
576
|
|
4
|
Ties
|
pieces
|
42
|
48
|
60
|
42
|
48
|
| Comparison of Distribution Frame | |||
| SN | Specifications | SUN-ODF-HA | SUN-ODF-HD |
| 1 | Maximum Number of Cores | 504/576/720 | 504/576 |
| 2 | Adaptor Type | SC/DLC or FC square (ST can be customized) | |
| 3 | Cabinet Material | Cold-rolled sheet (1.2mm thick) | |
| 4 | Max. No. of Splitters | 2 | 6 |
| 5 | Differnce | Splicing done directly (Without tray) | Splicing done inside the box |
| 6 | Installation type | Ground | |
| Model | Name | Description |
| SUN-ODF-HA504 | Fiber Optic Distribution Frame | Max. 504 cores; Height 2 m; Integrated splice trays NOT included |
| SUN-ODF-HA576 | Fiber Optic Distribution Frame | Max. 576 cores; Height 2.2 m; Integrated splice trays NOT included |
| SUN-ODF-HA720 | Fiber Optic Distribution Frame | Max. 720 cores; Height 2.6 m; Integrated splice trays NOT included |
| SUN-ODF-HD504 | Fiber Optic Distribution Frame | Max. 504 cores (with SUN-ODF-HD-MU72 ODF unit); Height 2 m; ODF units NOT included |
| SUN-ODF-HD576 | Fiber Optic Distribution Frame | Max. 576 cores (with SUN-ODF-HD-MU72 ODF unit); Height 2.2 m; ODF units NOT included |
| SUN-ODF-HD-MU12 | ODF Unit | 12 cores; SC / FC (square) panel; Suitable for SUN-ODF-HD series fiber optic distribution frames (ODF); Adapters NOT included |
| SUN-ODF-HD-MU24 | ODF Unit | 24 cores; SC / FC (square) panel; Suitable for SUN-ODF-HD series fiber optic distribution frames (ODF); Adapters NOT included |
| SUN-ODF-HD-MU48 | ODF Unit | 48 cores; SC / FC (square) panel; Suitable for SUN-ODF-HD series fiber optic distribution frames (ODF); Adapters NOT included |
| SUN-ODF-HD-MU72 | ODF Unit | 72 cores; SC / FC (square) panel; Suitable for SUN-ODF-HD series fiber optic distribution frames (ODF); Adapters NOT included |
| SUN-ODF-H-T | Integrated Splice Tray | 12 cores; SC / FC (square) panel; Suitable for SUN-ODF-HA series fiber optic distribution frames (ODF) or SUN-ODF-HD-MU series ODF unit; Adapters NOT included |
