SUN-PDN-1802 Series Pre-connectorized Distribution Box

Model: SUN-PDN-1802

IP68; Max. 18 pre-connectorized adapters

    Key Features

  • Advanced structure design, easy operation and reasonable routing
  • Material PP
  • Moisture-proof, waterproof, dust-proof, anti-aging
  • IP68
  • Max. 18 pre-connectorized adapters
  • Wall/ Pole/ Aerial mounted
  • Description
  • Specifications
  • Ordering Information
  • Applications
  • FAQ
  • Product Video
  • Sun Telecom's SUN-PDN-1802 series fiber optic pre-connectorized distribution box is used as a distribution point for the feeder cable to connect with the drop cable in the FTTx communication network system. The fiber splicing, splitting, and distribution can be done in this box, and it provides solid protection and management for the FTTx network building.

  • Parameters Specification
    Model SUN-PDN-1802A
    Material Box PP
    Pre-connectorized Adapter1 Number 18
    Adapter Type B/C/D/E/H
    Suitable Splitter Type 1x2 FBT (70/302) + 1x16 blockless type PLC splitter
    IP IP68
    Color Black
    Temperature Range (°C) -40 ~ +85
    Relative Humidity (%) (+30°C) ≤85
    Atmospheric Pressure (Kpa) 70~106
    Dimensions (mm) 199(L) x 193(W) x 107(H)
    Installation Method Wall/ pole/ aerial

    Note: 1. Pre-connectorized adapters



    2. 1x2 FBT (70/30), other splitting rations are optional, for example: 90/10, 80/20, 70/30, 60/40, 50/50

    Structure Drawing


    Installation

  • Ordering Information (For example)
    SUN-PDN-1802A-37-CSC-BPW
    Fiber Optic Distribution Box
    Pre-connectorized multiport distribution box; Loaded with 1pc 1×2 FBT (70/30) and 1×16 PLC splitter and 18pcs type C adapters (SC); Black color, dimensions (mm): 199(L) x 193(W) x 107(H); Including wall and pole mounting accessories

  • ● FTTH access networks
    ● Telecommunication networks
    ● CATV networks
    ● Local area networks
