RS-232 ⁄ 485 ⁄ 422 to Fiber Converter
| Item | Specification |
| Standard | EIA RS-232/485/432 |
| Transfer Rate (kbps) | 0-120, auto sense signal rate |
| Transmission Distance | RS232 port 15m RS485/422 port 1200m Optic port multi-mode 2-5km Single-mode 20-120km |
| Type | RS-232/485/422 DB-9 female, optic port SC, ST or FC |
| Optical Wavelength (nm) | 1310 (SM & MM) |
| Transmission Rate (kbps) | 0 ~ 500 |
| Operating temperature (℃) | -25 to 70 |
| Storage temperature (℃) | -40 to 85 |
| Humidity | Relative humidity 5% to 95% |
| Power input (V) | 48 DC |
| H*W*L (mm) | 100x69x22 (Power External) |
| Color | White |
| Weight (g) | 260 |
Fiber Optic Patchcord
Model:
Different interface optional, Easy operation, Low insertion loss
Features
Low insertion loss High return loss Good repeatability
SUN-GE9100B-VS Optical Line Terminal (OLT)
Model: SUN-GE9100B-VS
2/4/8/16 PON ports
Features
Space saving Convenient for installation and maintenance Maximum 16×PON, 8×Gigabit optical uplink and 8×Gigabit copper uplink ports
SUN-DC240 FTTH Indoor Cable
Model: SUN-DC240
Drop Cable, 1~4 cores, G657, flame retardent, for FTTH application
Features
Good crush resistance ensured by parallel strength member Low smoke, zero halogen sheath Simple Structure, light weight and high practicability
SUN-OT5000 OTDR
Model: SUN-OT5000
Can test SM and MM fibers, optional light source, VFL and power meter
Features
Quick startup FTTX in-service testing (Up to1:64 splitter) Built-in PON power meter for Triple-play testing (Only for SUN-OT5000-PON) High configuration series include optical light source, optical power meter, visual fault locator (VFL) and Optical Connector Inspector (MCI) modules USB data interface (PC software for batch data processing and report output) Dustproof and shockproof (2-meter drop test) Light weight, small size, rugged design and simple operation Visual link image software (Optional)
SUN-OPM200 Optical Power Meter
Model: SUN-OPM200
FC ⁄ SC ⁄ ST, REF, backlight control, USB port
Features
User self-calibration function Power measurements in dBm or mW Auto power off after 10 minutes without operation Standard FC/SC/ST interchangeable port Backlight LCD display for night operation REF setting function Intelligent backlight control Auto wavelength and frequency identification High storage capacity USB communication port for data transfer
SUN-ODB-RM2C Fiber Optic Terminal Box
Model: SUN-ODB-RM2C
19-inch Rack mount sliding type
Features
19-inch standard structure Sliding design, rack mounted FC square/SC/DSC/ST adapter panel
SUN-OC-SLT-SP GYTS Cable
Model: SUN-OC-SLT-SP
GYTS, Loose Tube Light-armored (Steel Tape) Cable, 2~144cores
Features
Good mechanical and temperature performance High hydrolysis resistance and high strength loose tube Good crush resistance and flexibility High tensile strength ensured by steel wire Good moisture-proof ensured by PSP Gopher protected cable
