900μm, Buffer material: PVC or LSZH
| Parameters | Specification | |
| Cable Diameter (mm) | 900 ± 50 | |
| Cable Weight (kg/km) | 0.9 | |
| Fiber Type (Core/cladding) (um) | 9/125, 50/125, 62.5/125 | |
| Material of Jacket | PVC or LSZH | |
| Tensile Strength (N) | Short Term | 6 |
| Long Term | 3 | |
| Bending Radius (mm) | Dynamic | 20D |
| Static | 10D | |
| Attenuation (After Cable (dB/km) | MM Fiber @850nm | ≤ 3.5 |
| MM Fiber @1300nm | ≤ 1.5 | |
| SM Fiber @1310nm | ≤ 0.4 | |
| SM Fiber @1550nm | ≤ 0.3 | |
| Operating Temperature (°C) | -20 ~ +60 | |
| Storage Temperature (°C) | -20 ~ +60 | |
Fiber Optic Patchcord
Model:
Different interface optional, Easy operation, Low insertion loss
Features
Low insertion loss High return loss Good repeatability
Fiber Optic Connector
Model:
FC/SC/ST/LC/MTRJ/MPO and other connectors
Features
Low insertion loss and high return loss Excellent interchangeability and repeatability High Precision Alignment
SUN-PM100L Fiber Optic Polishing Machine
Model: SUN-PM100L
Suitable for mass production
Features
Good polishing performance Easy operation FC, SC, LC connector polishing tray are optional Stainless steel body, sturdy and durable
SUN-IRL-A Insertion and Return Loss Tester
Model: SUN-IRL-A
In-built multiple-wavelength light source: 650/850/1310/1550nm
Features
Intelligent microprocessor-controlled equipment Insertion and return loss testing of the optical active devices and passive components In-built multiple-wavelength light source: 650/850/1310/1550nm In-built high stability light source (US import detector) Large color LCD screen
SUN-TK200S-I Fiber Optic Tool Kit
Model: SUN-TK200S-I
Suitable for polishing FC ⁄ SC ⁄ ST ⁄ LC connectors
Features
Easy to carry All kinds of tools
SUN-ODF-H Fiber Optic Distribution Frame
Model: SUN-ODF-H
Max cores: 504/576/720, HD series can be used with ODF units
Features
Electrostatic spraying technology adopted Suitable for installation of FC square, SC, DLC (SC type) adaptors Reliable fiber optic protection, flexible frame fixing and grounding devices Proper patching management
SUN-ODN-H Fiber Optic Distribution Box
Model: SUN-ODN-H
Indoor, Max adaptors: 1 ⁄ 2, SC, DLC adaptors
Features
Indoor flush mount SC adapter panel Fast connector applicable
SUN-1000 Media Converter
Model: SUN-1000
10/100/1000Mbps, 1xRJ45, 1xOptical port
Features
1000Mbps transmission rate Compliance with IEEE standards MTBF of more than 50000 hours Full & half duplex operation and auto-negotiation Electric interface self-adapting parallel/crossover connections Longest 1552 byte data packet transmission QoS ensuring VoIP data packet transmission STP Spanning Tree forming a redundant network Low power consumption and low heat for longtime stable operation Single/Multi mode and Single/Dual fiber transmission modes Network Management Function (optional)
SUN-VFL Visual Fault Locator
Model: SUN-VFL
650nm laser source, portable size and easy to carry
Features
Portable size and easy to carry 650nm visible laser source Suitable for various optical fibers
SUN-OT5000 OTDR
Model: SUN-OT5000
Can test SM and MM fibers, optional light source, VFL and power meter
Features
Quick startup FTTX in-service testing (Up to1:64 splitter) Built-in PON power meter for Triple-play testing (Only for SUN-OT5000-PON) High configuration series include optical light source, optical power meter, visual fault locator (VFL) and Optical Connector Inspector (MCI) modules USB data interface (PC software for batch data processing and report output) Dustproof and shockproof (2-meter drop test) Light weight, small size, rugged design and simple operation Visual link image software (Optional)
SUN-GE9100B-VS Optical Line Terminal (OLT)
Model: SUN-GE9100B-VS
2/4/8/16 PON ports
Features
Space saving Convenient for installation and maintenance Maximum 16×PON, 8×Gigabit optical uplink and 8×Gigabit copper uplink ports
